BHT-1400 Series
The benefits of a large-screen terminal are enhanced with Bluetooth® connectivity and Windows OS (Embedded Compact 7). Made for durability and maximum productivity in the field, especially in applications for retail, manufacturing, and warehousing. Comes with a free, three-year warranty upon product registration.
Does the Job in Style
Large, Color Screen Operation
The 3.2-inch WVGA screen affords a display area that is 15 percent larger than typical 2.4-inch QVGA screen. High resolution (480 x 800 dots) ensures crystal clear visibility in all ambient light levels, even bright sunlight.
For Any Environment
With an IP65 rating, you can have confidence that the BHT-1400 is performing as expected under the harshest of conditions.
More than Tough
The highly durable, impact-resistant BHT-1400 achieves best-in-class impact resistance in multiple drop tests from a height of 2 meters (6.5 feet).
Single-Handed Operation
A contoured, ergonomic design with nonslip grip is easy to hold and allows one-thumb operation.
Boost Your Uptime
Even with the wireless function always enabled, you get continuous operation up to 30 hours between charging.
Plug-In Power
A remote desktop plug-in and web browser plug-in enable thin client implementation while eliminating the need to develop applications for each device. Since the device itself contains no data, there are no security concerns.
Unfailing Global Support
Wherever you are, DENSO’s global support offers local on-site service and/or authorization for expedited factory returns should repair or replacement be needed.
Dimensions
Specifications
| Model Number | BHT-1461QWB-CE | BHT-1461BWB-CE |
| 2D Code Model | 1D Barcode Model | |
System |
||
| Operating System | Windows® Embedded Compact | |
| CPU | ARM Cortex-A8 800MHz | |
| Flash ROM | 2.0GB (1.2GB for user area) | |
| Card Slot | microSDHC or microSD (up to 32GB) x 1 (FAT32 compliant) | |
Display |
||
| Resolution (1) | 3.2 in. WVGA (480 x 800 px) | |
| Device | Color LCD | |
| Backlight | White LED | |
| Touchscreen | Resistive; working load: 1N | |
Scanner |
||
| Method | Area Sensor | Advanced Scan Plus (CCD) |
| Readable 2D Codes | QR code, micro QR code, SQRC, iQR code, PDF417, micro PDF417, Maxi code, DataMatrix (ECC200), GS1 Composite | — |
| Readable 1D Barcodes | EAN-13/8(JAN-13/8), UPC-A/E, UPC/EAN (add-on embedded), Interleaved 2 of 5 (ITF), Standard 2 of 5 (STF), CODABAR (NW-7), CODE39, CODE93, CODE128, GS1-128(EAN-128), GS1 Databar (RSS) | |
| Minimum Resolution 2D Codes | 0.167mm | — |
| Minimum Resolution 1D Barcodes | 0.125mm | |
| Reading Reference Position | 100mm | 110mm |
| Marker | Area Guide | — |
| Scan Confirmation | LED Light (blue and red), Sound and Vibration | |
| Keypad | 21 keys (including power key) + cross cursor key + 3 trigger Keys | |
Wireless LAN Communication |
||
| Standard | IEEE802.11b/g/n Compliant | |
| Frequency | 2.4GHz | |
| Communication Distance (2) | IEEE802.11n: indoors = approx. 50m, IEEE802.11b/g/n: indoors = approx. 75m, outdoors = approx.200m | |
| Transmission Speed (2) | IEEE802.11b: 11/5.5/2/1Mbps, IEEE802.11g: 54/48/36/24/18/12/9/6Mbps, IEEE802.11n: 65/58.5/52/39/26/19.5/13/6.5Mbps | |
| Access Method | Infrastructure Mode | |
| Security | WEP40, 128, WPA-PSK (TKIP,AES), WPA2-PSK (TKIP, AES), WPA-1x (TKIP, AES/EAP-TLS, PEAP, LEAP, EAP-FAST), WPA2-1x (TKIP, AES/EAP-TLS, PEAP, LEAP, EAP-FAST), 802.1x (WEP/EAP-TLS, PEAP, LEAP, EAP-FAST) | |
Bluetooth Communication |
||
| Bluetooth Ver.2.1 + EDR-based Class 2 | ||
Power |
||
| Main Battery | Lithium-ion Battery | |
| Operating Time (3) | 35 hours (4) / 32 hours (5) | 36 hours (4) / 30 hours (5) |
Operating Environment |
||
| IP Rating | IP65 | |
| Temperature Range (6) | -20 to 50°C | |
| Humidity | 10 to 90 % RH (no condensation or freezing) | |
| Drop Test (7) | 2.0m/1.5m above concrete floor, on all 6 faces, 10 times each (total 60 times) | |
Physical Characteristics |
||
| Weight (including battery) | Approx. 255g | |
|
||
Optional Accessories – Sold Separately
Batteries and Accessories | Part # |
|
| Standard Battery | 2,300mAh | BT-110LA |
| Standard Battery and Door/Cover | Bundled BT-110LA battery (2,300mAh) and door/cover | BT-140LA-C |
Charging Station |
||
| AC Adapter | Output: DC 12V - 4.16A Input: 100 to 240 V AC ±10%. For Brazil and Europe. | AD3-3012/3000 |
| AC Adapter | Output: DC 12V - 4.16A Input: 100 to 240 V AC ±10%. For USA, Canada and Mexico. | AD3-2012/300002 |
| Four-slot Cradle Charger | Charge up to four terminals at the same time. AC adapter not included. | CH-A4-14 |
| Four-slot External Battery Charger | To charge BT-110LA, BT-110L, BT-130LA or BT-20LB batteries. Charge up to four batteries at the same time. AC adapter not included. | CH-1104 |
Communication Station |
||
| AC Adapter | Output: DC 5V - 1.5A Input: 100 to 240 V AC ±10%. For Brazil only. | AD2-3005/3000 |
| AC Adapter | Output: DC 5V - 1.5A Input: 100 to 240 V AC ±10%. For USA, Canada and Mexico. | AD2-2005/300003 |
| Cable | Straight 14m USB cable. Type A Male - Type B Male | CB00US14004A4B1 |
| Cable | Straight 15m RS-232C | CB00RS1500/9901 |
| Single-slot Ethernet Cradle | For communication and battery charging. Ethernet cable and AC adapter not included. | CU-AL1-14 |
| Single-slot Serial RS232C Cradle | For communication and battery charging. RS232C cable and AC adapter not included. | CU-AR1-14 |
| Single-slot USB Cradle* | For communication and battery charging. USB cable and AC adapter not included. | CU-AU1-14 |
Other Accessories |
||
| Belt Holster | WHBHT-1400 | |
| Neck Strap | NS-BHT1300 | |
| Soft Case | SCBHT-1400 | |
Related Software
Software
Description
Part #
BHT-DMS Lite Device Management Software Lite Version. One license per PC. SW-BHTDMS-LITE
BHT-DMS Standard Device Management Software Standard Version. One License per PC. SW-BHTDMS-STRD
BHT-Windows Simulator Software to support program development and debug using virtual BHT running on the PC. One (1) license required by PC. SWBHT-WINSIM
SDK Windows Embedded 7 Compact Software Development Kit (SDK) for Windows Embedded Compact 7 Free download
Version Manager Version Manager for Windows BHT - Client Software to manage OS and Application Version One (1) license required by each BHT. Only for BHT-1461BWB-CE, BHT-1461QWB-CE, BHT-1261BWB-CE7, BHT-1261QWB-CE7, BHT-1361BWB-CE and BHT-1361QWB-CE SWBHT-VERMGR-W7
Wavelink License - IBM5250 Emulation License Wavelink TE 2in1 - Emulation IBM5250. Must purchase a one- or three-year warranty. SW-WVTEBHT14B52
Wavelink License - IBM5250 Emulation License Wavelink TE 2in1 - Emulation IBM5250. Must purchase a one- or three-year warranty. SW-WVTEBHT14Q52
Wavelink License - VT Emulation License Wavelink TE 2in1 - Emulation VT. Must purchase a one- or three-year warranty. SW-WVTEBHT14BVT
Wavelink License - VT Emulation License Wavelink TE 2in1 - Emulation VT. Must purchase a one- or three-year warranty. SW-WVTEBHT14QVT
Wavelink License One-year Warranty One-year warranty service for Wavelink license from DENSO Wave TE2IN1-AM-1Y-DW
Wavelink License Three-year Warranty Three-year warranty service for Wavelink license from DENSO Wave TE2IN1-AM-3Y-DW
All software can be downloaded from DENSO Wave’s QBdirect. Free software and drivers can be used immediately. Other software packages are available as trials. Please contact DENSO ADC to purchase a full license.
